Hardware

Network Standards:

• IEEE 802.3

• IEEE 802.3u

• IEEE 802.3x

• IEEE 802.3ab

LED Indicator:

• 1 × Power

• 5 × Link/Act

Interfaces:

• 5 × 10/100/1000 Base-T Ethernet ports (Auto MDI/MDIX)

Transmission Media:

• Recommended: CAT5/5e UTP or better

Dimension:

• 82 mm × 52 mm × 22 mm

Material:

• Plastic

Level of Protection (ESD):

• Air discharge: ±8kV

• Contact discharge: ±6kV

Forwarding Mode:

• Store-and-forward

Switch Capacity:

• 10 Gbps

Packet Forwarding Rate:

• 7.44 Mpps

Buffer:

• 1 Mb

MAC Address Table:

• 2K

Power:

• Input: 100-240V AC 50/60Hz

• Output: 5.0V 0.6A (External Power Adapter)

Power Consumption:

• Max: <3W

Mounting:

• Desktop mounting: support

• Wall mounting: support

Environment:

• Operating Temperature: 0°C – 45°C

• Storage Temperature: -40°C – 70°C

• Operating Humidity: 10% – 90% RH, non-condensing

• Storage Humidity: 5% – 90% RH, non-condensing

Certification:

• FCC, CE, RoHS

Software

Protocols:

• CDMA/CD

MAC Address Learning:

• Auto-Learning and Auto-Aging

Functions:

• Plug-and-play
