Hardware
Standard & Protocol:
IEEE 802.3, IEEE 802.3u
CPU:
1 GHz
RAM:
32 MB
Interfaces:
1 × 10/100 Mbps WAN port
3 × 10/100 Mbps LAN ports
Antenna:
4 × 6 dBi external antennas
Button:
1 × Wi-Fi / Reset button
Power:
Input: 100-240V ~ 50/60Hz, 0.4A
Output: DC 9V 1A
LED Indicator:
SYS × 1
Dimension:
200 × 127 × 33.6 mm
Wireless
Wireless Standard:
5GHz: IEEE 802.11ac/a/n
2.4GHz: IEEE 802.11b/g/n
Data Rate:
5GHz: Up to 867 Mbps
2.4GHz: Up to 300 Mbps
Frequency:
CE:
2.4GHz: 2412-2472 MHz (CH1-CH13)
5GHz: 5150-5250 MHz (CH36-CH64)
FCC:
2.4GHz: 2412-2462 MHz (CH1-CH11)
5GHz: 5150-5250 MHz (CH36-CH64), 5725-5825 MHz (CH149-CH165)
Transmission Power:
CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
FCC: <30 dBm (2.4 GHz & 5 GHz)
Wireless Security:
WPA2-PSK
Wireless Security: Enable/Disable
Basic Functions:
SSID Broadcast
Signal Adjustment
Software / Features
Internet Connection Type:
PPPoE, Dynamic IP, Static IP
PPPoE (Russia), PPTP (Russia), L2TP (Russia)
Unify, Maxis, Maxis-special, Celcom, Digi
Network Protocol:
IPv4 & IPv6
Operating Modes:
Router Mode
AP Mode
Universal Repeater Mode (Client + AP, WISP)
Parental Control:
Client Filter
URL Filter
Time Limit
DHCP:
DHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Allocation
Virtual Server:
Port Forwarding
DMZ Host
UPnP
Firewall:
ICMP Flood Attack Defense
TCP Flood Attack Defense
UDP Flood Attack Defense
Block Ping From WAN
DDNS:
DynDNS, no-ip, oray, 88ip
VPN:
IPsec pass through
PPTP pass through
L2TP pass through
Special Features:
Guest Network
IPTV
Signal Adjustment
Additional Functions:
PPPoE Username/Password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED On/Off
Tenda App
Dual-Band in One
IPv6 Features Supported
Broadband Management
MAC Address Clone
Backup & Restore Configurations
Firmware Upgrade From Local
Environment
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃
Operating Humidity: 10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90% RH non-condensing
Certification:
CE, FCC, RoHS
Package Contents:
Wi-Fi Router × 1
RJ45 Ethernet Cable × 1
Power Adapter × 1
Quick Installation Guide × 1
