Product Information

Model:

• O8

Dimension:

• 391.5 × 280 × 223 mm

Deployment:

• Pole Mount

Application Scenarios:

• PtP and PtMP wireless connection for Private ISP access or CCTV Surveillance

Hardware

Frequency Range:

• 5GHz

Compliant Standards:

• IEEE 802.11a/n/ac

Private TDMA Protocol:

• TD-MAX

Maximum Wireless Rate:

• 433 Mbps

Interfaces:

• 1 × 10/100 Mbps Ethernet Port

Antenna Polarization:

• Vertical Polarization

Antenna Gain:

• 23 dBi

Antenna Beamwidth:

• Vertical: 10°

• Elevation: 10°

Reset Button:

• 1

Power Consumption:

• 5.5 W

Waterproof Level:

• IP65

LED Indicator:

• PoE/LAN, LED1, LED2, LED3

Power Method:

• 12V 1A Passive PoE

Lightning Protection:

• 6000V

Passive PoE:

• Passive power over Ethernet via PoE/LAN (+4,5 pins, -7,8 pins)

• Voltage range: 9-35V DC

Reception Sensitivity:

• 11a 6Mbps: -95dBm ±1.5dBm

• 11n MCS7 HT20: -72dBm ±1.5dBm

• 11ac MCS9 HT80: -64dBm ±1.5dBm

Software / Features

TDMA:

• Support

Operating Modes:

• AP / Station / WISP / P2MP / WDS Repeater / Router

Wireless Management:

• Enable/Disable Wireless Radio: Support

• SSID Hidden: Support

• Wireless Client Isolation: Support

• SSID Isolation: Support

• Channel Bandwidth: 20 / 40 / 80 MHz

• Channel Shift: Support

• Wireless Access Control: Support

• Weak Signal Client Limitation: Support

• Transmission Power: Adjustable by 1 dBm

• WMM Capable: Support

• APSD Capable: Support

• Wireless Security: 64/128 WEP, WPA-PSK, WPA2-PSK, WPA

• Transparent Bridge: Support

• VLAN Tagging for SSID: Support

Network Services:

• DHCP Server: Support

• VPN Pass-Through: PPTP, L2TP

• Remote Web Access: Support

• Schedule Reboot: Support

• Page Timeout: Support

• Ping Watchdog: Support

• DynDNS: noip, dyndns.org

• Network Diagnostics: Ping, Traceroute, Signal Scan

• Time and Date Setting: Support

Firmware / Management:

• Firmware Upgrade: Support

• Backup / Restore Configuration: Support

• Username Management: Support

• System Logs: Support

• Managed By Controller: PC Software – CPE Assistant

Others

Package Contents:

• 1 × 5GHz 23dBi 11ac Outdoor CPE O8

• 1 × Power Adapter

• 1 × PoE Injector

• 1 × Quick Installation Guide

Operation Temperature:

• -30°C ~ 60°C

Storage Temperature:

• -40°C ~ 70°C

Operating Humidity:

• 10% ~ 90% non-condensing

Storage Humidity:

• 10% ~ 90% non-condensing

Default Login:

• IP: 192.168.2.1

• Username: admin

• Password: admin

Certification:

• FCC / CE / RoHS
