Key Specifications

Hardware Specifications

Antenna

• Antenna: 4 x external antennas
• Antenna gain (2.4 GHz): 4 dBi
• Antenna gain (5 GHz): 5.5 dBi

Wi-Fi Radio

• FEM: iPA
• Max. Wi-Fi Speed: 2.4 GHz, 400 Mbps; 5 GHz, 867 Mbps
• Wi-Fi standard: Wi-Fi 5 (IEEE 802.11 ac)

Software Specifications

Network Management and Monitoring

• Ruijie Cloud management: Yes

Reyee Mesh 3.0

• Reyee Mesh 3.0: Yes

System Performance Capacity

• Maximum number of concurrent clients: 32 (2.4 GHz), 64 (5 GHz)
• Recommended number of concurrent clients: 8 (2.4 GHz), 24 (5 GHz)
