General
| Shell | Metal material |
| Net Weight | 0.27 kg (0.60 lb) |
| Gross Weight | 0.52 kg (1.15 lb) |
| Dimensions (W × H × D) | 145 mm × 68.45 mm × 25.6 mm (5.71” × 2.69” × 1.01”) |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | –40 °C to 85 °C (–40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 48 VDC, 0.8 A |
| Installation Mode | Desk-Mounted, Wall-Mounted |
| Max. Power Consumption | 38 W |
| Power Consumption in Idle | 3 W |
| Surge Protection | 6 KV |
Network Parameters
| Ports | 4 x 10/100 Mbps PoE port, 2 × 10/100 Mbps RJ45 port |
| MAC Address Table | 2 K |
| Switching Capacity | 1.2 Gbps |
| Packet Forwarding Rate | 0.89 Mpps |
| Internal Cache | 768 Kbits |
PoE Power Supply
| PoE Standard | IEEE 802.3af; IEEE 802.3at |
| PoE Power Pin | 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | PoE: Ports 1 to 4 |
| Max. Port Power | 30 W |
| PoE Power Budget | 35 W |
Dialing Function
| Long Range | Ports 1 to 4: up to 300 m. Long range performance may vary depend on camera model or cable condition. |
Software Function
| VIP Port | Ports 1 to 2: data on VIP ports is preferentially forwarded when bandwidth resources are insufficient. |
Approval
| EMC | FCC (47 CFR Part 15, Subpart B), CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020), IC (ICES-003: Issue 7:2020), RCM (AS/NZS CISPR 32: 2015) |
| Safety | UL (UL 60950-1), CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Chemistry | CE-RoHS (2011/65/EU) WEEE (2012/19/EU) Reach (Regulation (EC) No. 1907/2006) |
