Software Features

• Zones: 64 (8 On-board zones, max 8 wired PIRCAM)

• Area: 32

• User:

  • Installer: 1

  • Administrator: 1

  • Operator: 62

• SMS Notification: Support (with GPRS/3G/4G module)

• Onboard Video Clips: 4

• ARC Protocol:

  • ISAPI: Supports iVMS-4200 client software and web client

  • Cloud P2P: Supports cloud P2P privacy protocol

  • DC-09: ARC accessible (ADM-CID/SIA-DCS)

  • CSV-IP: Supports CSV-IP

  • ISUP: Supports ISUP 5.0

• Programming Tools: Web/iVMS-4200/Hik-Partner Pro/Keypad

• Firmware Upgrade: Web/iVMS-4200/Hik-Partner Pro

• End of Line Resistance: Support 1K, 2.2K, 4.7K, 5.6K, 6.8K, 8.2K

Hardware Features

• Alarm Input: 64 (Including 8 on-board zones)

• Alarm Output: 64 (Including 2 on-board relay outputs and 2 on-board I/O outputs)

• Power Output:

  1. Bell: maximum 12V 1.2A

  2. AUX: maximum 12V 1.5A

• 3/4G On Board: Optional

• GPRS On Board: Optional

• Wi-Fi: 802.11b/g/n (2.4GHz)

• Bus: 1 Speed-X bus

• Sounder Output: 1 Wired on-board sounder output

• Tamper-Proof:

  • 1 switch to detect removal from mounting

  • 1 switch to detect front cover open

Network Interface

• 1 RJ45 10M/100M Ethernet interface

Display Indicator

• 4 On-board LEDs:

  1. AC power LED indicator (Green)

  2. System status LED indicator (Green/Red)

  3. PSTN status LED indicator (Green/Red)

  4. Mobile communication status LED indicator (Green/Red)

Electrical Characteristics

• Power Interface: 100 to 240 VAC (on-board power transformer)

• Power Consumption:

  1. 220V power supply

     • With an alarm: 2A, 32W

     • Without an alarm: 250mA, 4W

  2. 13.5V battery supply

     • With an alarm: 1.7A, 25W

     • Without an alarm: 200mA, 2.7W

• Battery Type: Lead acid battery (12V 7Ah, battery is not included by default)

• Battery Life Span: Up to 36hrs

General

• Operation Temperature: -10°C to 40°C

• Operation Humidity: 10% to 90%

• Shell Material: Plastic

• Color: White

• Dimension (WxHxD): 261 mm × 199 mm × 86.4 mm

• Weight: 997 g

Device Management

• Tag: 64

• Keyfob: 64

• Keypad: 8

• Wireless Sounder: 16
