EZVIZ CS-H6C 3MP 360° Home Security Camera

Specifications
Model	CS-C6c-R100-1H3WF
Camera
Image Sensor	1/2.7″ Progressive Scan CMOS
Shutter Speed	Self-adaptive shutter
Lens	4mm @ F2.0, viewing angle: 100° (Horizontal), 84° (Vertical), 46° (Diagonal)
PT Angle	Pan: 340°, Tilt: 130°
Minimum Illumination	0.51 Lux @ (F2.0, AGC ON) with IR
Lens Mount	M12
Day & Night	IR-cut filter with auto switch
DNR	3D DNR
WDR	Digital WDR
BLC	Supports
Night Vision	Up to 10 m
Video & Audio
Max. Resolution	2304 × 1296
Frame Rate	Max. 25 fps; Self-Adaptive during network transmission
Video Compression	H.264/H.265
Video Bit Rate	HD; Standard. Adaptive bit rate.
Audio Bit Rate	Self-Adaptive
Max. Bitrate	3 Mbps
Network
Wi-Fi Standard	IEEE 802.11 b, 802.11 g, 802.11 n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	Supports 20 MHz
Security	64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Transmission Rate	11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
Wi-Fi Pairing	AP paring
Protocol	EZVIZ Cloud Proprietary Protocol
Interface Protocol	EZVIZ Cloud Proprietary Protocol
Wired Network	RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
Function
Smart Alarm	Human Shape Detection, Image Change Detection
Customized Alert Area	Supports
Two-Way Talk	Supports (Two Mic)
General Function	Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark
Storage
Local Storage	Micro SD card slot (Max. 512G)
Cloud Storage	EZVIZ CloudPlay storage
General
Operating Conditions	-10° to 45° C (14° to 113° F) Humidity 95% or less (non-condensing)
Power Supply	DC 5V/1A (Type-C)
Power Consumption	MAX. 5W
Product Dimensions	100 × 100 × 96.5 mm
Packaging Dimensions	115.5 × 116 × 160 mm
Weight	Net weight: 255 g (8.99 oz) With package: 487 g (17.18 oz)
In the box
In the box	– Camera
	– Power Adapter
	– Power Cable
	– Drill Template
	– Mounting Plate
	– EZVIZ Screw Kit
	– Regulatory Information
	– Quick Start Guide
Certifications
Certifications	CE (EMC / LVD / RED / ROHS) / UKCA / REACH SVHC / WEEE / FCC / UL
