Specification

Facial Recognition

• Face Picture Library: Up to 16 face picture libraries; HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.
• Face Picture Comparison: 4-ch face picture comparison alarm (HD analog camera)

Perimeter Protection

• Human/Vehicle Analysis: Up to 8-ch (advanced model)

Facial Detection

• Facial Detection and Capture: Face picture detection, face picture search; 4-ch face picture capture

Video and Audio

• IP Video Input: 8-ch (up to 16-ch), each up to 4 Mbps; Support H.265+/H.265/H.264+/H.264 IP cameras
• Analog Video Input: 8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• HDMI Output: 1-ch, 4K (3840×2160)/30Hz, 2K (2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz; HDMI/VGA simultaneous output
• VGA Output: 1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz; HDMI/VGA simultaneous output
• CVBS Input: PAL/NTSC
• CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704×576, NTSC: 704×480
• Synchronous Playback: 8-ch
• HDTVI Input: 8 MP (3840×2160)@12/15 fps, 3K (2960×1665)@25/20 fps, 3K (3328×1504)@20 fps, 2K (2304×1296)@20 fps, 5 MP (2560×1944)@20 fps, 4 MP (2560×1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30 fps
• AHD Input: 5 MP (2560×1944)@20 fps, 4 MP (2560×1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30 fps
• HDCVI Input: 8 MP (3840×2160)@12/15 fps, 3K (2880×1620)@20/25 fps, 5 MP (2592×1944)@20 fps, 4 MP (2560×1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30 fps
• Audio Output: 1-ch, RCA (Linear, 1 KΩ)
• Audio Input: 1-ch (up to 8-ch is optional), RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable
• Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

Recording

• Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding Resolution: 8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
• Frame Rate:
  Main stream: 8 MP@8 fps / 3K@12 fps / 5 MP@12 fps / 4 MP@15 fps / 8 MP Lite@15 fps / 1080p/720p@25 fps (P)/30 fps (N)
  Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N)
• Video Bitrate: 32 Kbps to 10 Mbps
• Dual-stream: Support main stream or sub stream
• Stream Type: Video, Video & Audio
• Audio Compression: G.711u
• Audio Bitrate: 64 Kbps

Decoding

• Decoding Capability: Up to 24-ch 1080P@30fps

Network

• Total Bandwidth: 256 Mbps
• Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
• Remote Connection: 64
• Network Interface: 1 × RJ45 10M/100M/1000M self-adaptive Ethernet interface

Auxiliary Interface

• SATA: 1 SATA interface
• Capacity: Up to 12 TB capacity for each disk
• Serial Interface: RS-485 (half-duplex)
• USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
• Alarm In/Out: N/A (optional to support)

General

• Power Supply: 12 VDC, 2 A
• Consumption: ≤ 10 W (without HDD)
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10% to 90%
• Dimension (W × D × H): 319 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch)
• Weight: ≤ 2 kg (4.4 lb)
