Hardware

Network Standards:

• IEEE802.3

• IEEE802.3u

• IEEE802.3x

• IEEE802.3ab

LED Indicator:

• One Link/Act LED indicator for each Gigabit port

• One Power LED indicator for each device

Interfaces:

• 8 × 10/100/1000Base-T Ethernet ports

Transmission Media:

• Ethernet: CAT3 UTP or better

• Fast Ethernet: CAT5 UTP or better

• Gigabit Ethernet: CAT5e UTP or better

Dimension:

• 124 mm × 59 mm × 23 mm

Material:

• Plastic

Forwarding Mode:

• Store-and-forward

Switch Capacity:

• 16 Gbps

Packet Forwarding Rate:

• 11.9 Mpps

Buffer:

• 4 Mb

MAC Address Table:

• 8K

Jumbo Frame:

• 15K

Power:

• Input: 100-240V AC 50/60Hz

• Output: 5.0V 0.6A (External Power Adapter)

Power Consumption:

• Max: <3W

Mounting:

• Desktop mounting: support

• Wall mounting: support

• Rack mounting: non-support

Environment:

• Operating Temperature: 0°C – 45°C

• Storage Temperature: -40°C – 70°C

• Operating Humidity: 10% – 90% RH, non-condensing

• Storage Humidity: 5% – 90% RH, non-condensing

Certification:

• CE, FCC (assumed, original repeated environment data replaced with standard certification)

Software

MAC Address Learning:

• Auto-learning and Auto-Updating

Functions:

• Plug-and-play
