Key Specifications
Product Information
Product Category
- Product Category: Layer 2
Hardware Specifications
Product Information
- Warranty: 3 years
Port Specifications
- Total number of RJ45 ports: 24
- Total number of optical ports: 2
- Number of 1GE SFP ports: 2
- Number of 10/100/1000BASE-T ports: 24
Power Supply and Consumption
- Number of PoE Out ports: 24
- Number of PoE/PoE+ Out ports: 24
- PoE budget: 370 W
- PoE power pins: 1–2 (+), 3–6 (-)
System Specifications
- Forwarding rate: 38.7 Mpps
- Switching capacity: 52 Gbps(bit/s)
Environment and Reliability
- Operating temperature: 0°C to 40°C (32°F to 104°F)
Software Specifications
Basic Configurations
- PoE watchdog: Yes
Security
- Port isolation: Yes
Order Information
- Device: RG-ES226GC-P
- Power Supply: Power cable
- Quick Start Guide: 1
- Warranty Card: 1
- Accesories: Mounting bracket * 2, Foot pad * 4, Screws * 8
- Package Weight: 4.2 kg
- Package Dimension (w x d x h): 539 mm x 406 mm x 114 mm
