Product Category
Product Category
Product Category
- Product Category: Layer 2
Hardware Specifications
Product Information
- Warranty: 3 years
Port Specifications
- Total number of RJ45 ports: 10
- Total number of optical ports: 1
- Number of 1GE combo ports: 1
- Number of 1GE SFP ports: 1
- Number of 10/100/1000BASE-T ports: 10
Power Supply and Consumption
- Number of PoE Out ports: 8
- Number of PoE/PoE+ Out ports: 8
- PoE budget: 120 W
- PoE power pins: 1–2 (+), 3–6 (-)
System Specifications
- Forwarding rate: 14.8 Mpps
- Switching capacity: 20 Gbps(bit/s)
Environment and Reliability
- Operating temperature: 0°C to 40°C (32°F to 104°F)
Software Specifications
Basic Configurations
- PoE watchdog: Yes
Security
- Port isolation: Yes
Order Information
- Device: RG-ES210GS-P
- Power Adapter: 1
- User Manual: 1
- Power Code: 1
- Warranty Card: 1
- Shipping Weight: 1.65 kg (3.64 lbs)
1
Number of 1GE SFP ports
1
Number of 10/100/1000BASE-T ports
10
Power Supply and Consumption
Number of PoE Out ports
8
Number of PoE/PoE+ Out ports
8
PoE budget
120 W
PoE power pins
1–2 (+), 3–6 (-)
System Specifications
Forwarding rate
14.8 Mpps
Switching capacity
20 Gbps(bit/s)
Environment and Reliability
Operating temperature
0°C to 40°C (32°F to 104°F)
Software Specifications
Basic Configurations
PoE watchdog
Yes
Security
Port isolation
Yes
Order Information
Device RG-ES210GS-P
Power Adapter 1
User Manual 1
Power Code 1
Warranty Card 1
Shipping Weight 1.65 kg (3.64 lbs)
