Key Specifications
Product Information
Product Category
- Product Category: Layer 2+
Hardware Specifications
Product Information
- Warranty: 5 years
Port Specifications
- Total number of RJ45 ports: 8 (including eight combo ports)
- Total number of optical ports: 28 (including eight combo ports)
- Number of 1GE combo ports: 8
- Number of 1GE SFP ports: 24 (including eight combo ports)
- Number of 10GE SFP+ ports: 4
- Number of 10/100BASE-T ports: No
- Number of 10/100/1000BASE-T ports: 8 (including eight combo ports)
- Number of 10/100/1000/2500BASE-T ports: No
- Number of 100/1000/2.5G/5G/10GBASE-T ports: No
System Specifications
- Forwarding rate: 95.23 Mpps
- Switching capacity: 128 Gbps(bit/s)
Environment and Reliability
- MTBF: 400,000 hours
- Operating temperature: 0°C to +50°C (32°F to 122°F)
- Altitude: Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.); Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
- Surge protection: Service port: ±6 kV for common mode; Power connector: ±6 kV for both common mode and differential mode
Software Specifications
Basic Configurations
- PoE watchdog: No
Interface
- Jumbo frame length (MTU): 9216 bytes (interface configuration mode)
Security
- Port isolation: Yes
- Broadcast storm control: Yes
