Facial Recognition
| Face Picture Library | Up to 16 face picture libraries. HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash. |
| Face Picture Comparison | 4-ch face picture comparison alarm (HD analog camera) |
Motion Detection 2.0
| Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels. It can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights. Quick search by object or event type is supported. |
Perimeter Protection
| Human/Vehicle Analysis | Up to 8-ch (advanced model) |
Facial Detection
| Facial Detection and Capture | Face picture detection, face picture search; 4-ch face picture capture |
Video and Audio
| IP Video Input | 16-ch (up to 32-ch), each up to 4 Mbps Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
| Analog Video Input | 16-ch; BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI Input | 8MP@12/15fps, 3K@20/25fps, 3K@20fps, 5MP@20fps, 4MP@25/30fps, 1080P@25/30fps, 720P@25/30fps |
| AHD Input | 5MP@20fps, 4MP@25/30fps, 1080P@25/30fps, 720P@25/30fps |
| HDCVI Input | 8MP@12/15fps, 3K@25fps, 5MP@20fps, 4MP@25/30fps, 1080P@25/30fps, 720P@25/30fps |
| CVBS Input | PAL/NTSC |
| HDMI Output | 1-ch, 4K (3840×2160)/30Hz, 2K (2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output | 1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Video Output Mode | HDMI/VGA simultaneous output |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704×576, NTSC: 704×480 |
| Audio Input | 1-ch (up to 16-ch optional), RCA (2.0 Vp-p, 1 KΩ); 16-ch via coaxial cable |
| Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input) |
| Synchronous Playback | 16-ch |
Recording
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution | 8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Frame Rate | Main stream: 8 MP@8 fps / 3K@12 fps / 5 MP@12 fps / 4 MP@15 fps / 8 MP Lite@15 fps / 3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
| Video Bitrate | 32 Kbps to 10 Mbps |
| Dual-stream | Support main stream or sub stream |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711u |
| Audio Bitrate | 64 Kbps |
Decoding
| Decoding Capability | Up to 24-ch 1080P@30fps |
Network
| Total Bandwidth | 256 Mbps |
| Network Protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP |
| Remote Connection | 128 |
| Network Interface | 1, RJ45 10/100/1000 Mbps self-adaptive Ethernet interface |
Auxiliary Interface
| SATA | 2 SATA interfaces |
| Capacity | Up to 12 TB capacity for each disk |
| Serial Interface | RS-485 (half-duplex) |
| USB Interface | Front panel: 1 × USB 2.0 Rear panel: 2 × USB 3.0 |
| Alarm In/Out | N/A (optional to support) |
General
| Power Supply | 12 VDC, 5 A |
| Consumption | ≤ 15 W (without HDD) |
| Working Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| Working Humidity | 10% to 90% |
| Dimension (W × D × H) | 384 × 317 × 52 mm (15.1 × 12.5 × 2.0 inch) |
